Auk Class, U.S. Fleet Minesweepers


Photograph of Auk-class fleet minesweeper

DANFS. Computer enhanced by author

Schematic diagram of Auk class minesweeper

ONI 222


Specifications:


Tonnage

890 tons standard displacement

Dimensions

221'2" by 32'2" by 10'9"
67.41m by 9.70m by 3.28m

Maximum speed

18.1 knots

Complement

105

Armament

1 3"/50 dual-purpose gun
2 40mm Bofors AA guns
8 20mm Oerlikon AA guns
depth charge racks
4 depth charge throwers
Hedgehog
Machinery
2-shaft diesel-electric (3118 shp)
Bunkerage
200 tons
Range
6370 nautical miles (11,800 km) at 16.5 knots
Sensors
SF radar
QC sonar

The Auks were completed in 1942-45. A few were given special machinery to facilitate sweeping of magnetic mines; these are sometimes listed separately as the Raven class. All had significant antisubmarine capability and were routinely deployed as escorts, particularly when turned over to the British as Lend-Lease. They were capable of laying mines as well as sweeping them.


Units in the Pacific:

Sheldrake

completed 1942-10-14 (Alameda)

Starling completed 1942-12-21 (Alameda)
Skylark completed 1942-12-25 (Alameda)
Swallow completed 1943-1-14 (Alameda)
Token arrived 1943-4-9
Tumult arrived 1943-5-27
Velocity arrived 1943-6-24
Champion
completed 1943-9-8 (Alameda)
Chief
completed 1943-10-12 (Alameda)
Zeal arrived 1943-10-12
Competent
completed 1943-11-10 (Alameda)
Spear completed 1943-12-31 (Seattle)
Defense
completed 1944-1-10 (Alameda)
Devastator
completed 1944-1-10 (Alameda)
Triumph completed 1944-2-3 (Seattle)
Gladiator
completed 1944-2-25 (Alameda)
Vigilance completed 1944-2-28 (Seattle)
Impeccable
completed 1944-4-24 (Alameda)
Ardent
completed 1944-5-25 (Alameda)
Steady arrived 1945-2-22
Strive arrived 1945-2-22
Sustain arrived 1945-2-22
Staff arrived 1945-2-25
Speed arrived 1945-3-21
Surfbird arrived 1945-4-27
Toucan arrived 1945-4-27
Seer arrived 1945-5
Threat arrived 1945-5-1
Sway arrived 1945-5-3
Swift arrived 1945-5-3
Symbol arrived 1945-5-3
Wheatear
arrived 1945-5-14
Scoter arrived 1945-5-29


References

DANFS

Gogin (2010; accessed 2012-12-5)

NavSource.org (accessed 2009-1-21)

ONI 222 (1945-9-1)

Worth (2001)
